| Recording channel: |
2 |
| Recovery channel: |
2 |
| Recording format |
.WAV
(44.1kHz/16bit, 44.1kHz/24bit, 48kHz/16bit ,
48kHz/24bit, 88.2kHz/16bit, 96kHz/16bit) |
| Playback format: |
.WAV
(44.1kHz/16bit, 44.1kHz/24bit, 48kHz/16bit,
48kHz/24bit, 88.2kHz/16bit, 96kHz/16bit) |
| A/D conversion: |
24-bit, 128x oversampling |
| D/A conversion: |
24-bit, 128x oversampling |
| Signal processing |
32-bit |
| Recording media: |
Micro SD card (8-32GB)
MicroSDXC (64-128GB)
|
| LCD: |
LCD 128*64 ( with light ) |
| Built-in stereo mic: |
90° X/Y stereo configuration
Unidirectional condenser |
| Gain: |
0 to +45dB |
| Minimum gain with digital attenuation: |
-30dB |
| Microphone Input: |
3.5mm (1/8”) Stereo Microphone Input |
| Line Input: |
3.5mm (1/8”) Line Level Input |
| Input level: |
0 to -45dB |
| Output impedance: |
2 kΩ |
| Line output: |
3.5mm (1/8) stereo jack |
| Output load impedance: |
10 kΩ or more |
| Rated output level: |
-10dBm |
| Headphone output level: |
20mW + 20mW into 32Ω load |
| Built-in Speaker: |
1W 8Ω |
| USB jack: |
Type-C |
| Power required: |
LR6 or Ni-MH AA battery X 2
USB DC 5V
|
| Recording hours: |
Alkaline Battery
13.5 hours under 96kHz/16bit (wav)
19.5 hours under 44.1kHz/16bit (wav) |
| Weight: |
150g (5.3oz.) |
| Dimension: |
60 (W) x 167 (D) x 30 (H) mm |
